Mean Well HDR-60-15 is an ultra-slim 60W DIN rail power supply delivering a regulated 15V DC output. With a compact 52.5mm (3SU) width, it is ideal for installations where space inside control cabinets is limited.

The unit supports a universal 85–264VAC input (277VAC operational) and provides efficiency up to 89%. Cooling is achieved by free air convection, ensuring silent and reliable operation.

Key Specifications

• Output voltage: 15V DC

• Rated current: 4A

• Rated power: 60W

• Adjustable output range: 13.5–18V

• Ripple & noise: 120mVp-p

• Isolation class: II

• LPS (Limited Power Source)

Protections

• Short circuit protection

• Overload protection 105–160% (hiccup mode, auto recovery)

• Over voltage protection 18.8–22.5V

Environmental Conditions

• Operating temperature: -30°C to +70°C

• Humidity: 20–90% RH non-condensing

• Mounting: DIN rail TS-35/7.5 or TS-35/15

• Dimensions: 52.5 × 90 × 54.5 mm

• Weight: 190 g

• Warranty: 3 years

Ingress protection: IP20

Applications

• building automation

• industrial control systems

• control cabinets

• factory automation

• electro-mechanical equipment
