Mean Well MDR-10-24 is a compact 10W DIN rail switching power supply providing a regulated 24V DC output. It is designed for industrial automation, control systems, PLCs, sensors and other industrial equipment.

The unit supports a universal input range of 85–264VAC or 120–370VDC and provides efficiency up to 84%. Cooling is achieved by free air convection, ensuring silent and reliable operation.

Key Specifications

• Output voltage: 24V DC

• Rated current: 0.42A

• Rated power: 10W

• Ripple & noise: 150mVp-p

• Efficiency: up to 84%

• Frequency range: 47–63Hz

Protections

• Short circuit protection

• Overload protection >105% (hiccup mode, auto recovery)

• Over voltage protection 27.6–32.4V

Features

• DC OK signal for power status monitoring

• LED indicator for power on

• Low no-load power consumption <0.75W

Environmental Conditions

• Operating temperature: -20°C to +70°C

• Humidity: 20–90% RH non-condensing

• Mounting: DIN rail TS-35/7.5 or TS-35/15

• Dimensions: 22.5 × 90 × 100 mm

• Weight: approx. 0.15 kg

Ingress protection: IP20

Applications

• industrial automation

• control systems

• PLC controllers

• sensors and I/O modules

• control cabinets

Warranty: 3 years
