NDR-240-24 is a 240 W industrial DIN-rail power supply (24 V, 10 A) from Mean Well designed for industrial automation and control systems. The unit supports a universal 90–264 VAC or 127–370 VDC input range, allowing operation in a wide variety of power systems.

The power supply features built-in active power factor correction (PFC) to improve power efficiency and reduce load on the electrical network. Its 63 mm wide metal housing enhances heat dissipation while saving space in control cabinets. Maximum efficiency reaches up to 88.5%.

The unit includes constant current limiting for overload protection, making it suitable for inductive and capacitive loads. Full protection functions are provided including short circuit, overload, over-voltage and over-temperature protection. Fanless cooling by natural convection ensures reliable and silent operation.

With industrial safety approvals (UL508, EN62368-1) and high reliability, the NDR-240-24 is suitable for industrial control systems, factory automation, semiconductor manufacturing equipment and electro-mechanical applications.

Key specifications:

• output voltage: 24 V DC

• rated current: 10 A

• rated power: 240 W

• input voltage: 90–264 VAC / 127–370 VDC

• efficiency: up to 88.5%

• power factor: up to 0.95

• mounting: DIN rail TS-35

• width: 63 mm

• operating temperature: -20…+70 °C

• protections: short circuit / overload / over-voltage / over-temperature

• warranty: 3 years
