XDR-150E-12 — 150W Industrial DIN Rail Power Supply, 12V

The Mean Well XDR-150E-12 is a compact 150W AC/DC industrial power supply designed for DIN-rail mounting. The unit features an ultra-slim 30 mm wide housing, making it ideal for installations where cabinet space is limited.

It supports a wide input voltage range of 85–264VAC and provides efficiency up to 91%, ensuring reliable operation and energy savings.

The power supply includes built-in protections against short circuit, overload, over-voltage, and over-temperature. Its fanless design allows cooling by natural air convection for increased reliability in industrial environments.

The unit operates in a wide temperature range of −40 to +70°C and features a DC OK relay contact for output status monitoring.

Key features:

• Output voltage: 12V DC

• Rated current: 10–11A

• Output power: 120–156W

• Input voltage range: 85–264VAC / 120–370VDC

• Efficiency: up to 91%

• Output voltage adjustment: 12–15V

• Protections: short circuit / overload / over-voltage / over-temperature

• Operating temperature: −40…+70°C

• Mounting: DIN rail TS-35

• Ultra-slim 30 mm width

• Built-in DC OK relay contact

• Protection class: IP20

• 3-year warranty

Applications:

• industrial control systems

• semiconductor manufacturing equipment

• factory automation

• electro-mechanical equipment

• battery charging systems
