XTR-480-12 is a 480 W ultra-slim three-phase DIN-rail power supply (12 V, 30 A) from Mean Well designed for industrial automation and control systems. The unit supports a wide three-phase input range of 320–600 VAC and features a compact 63 mm wide housing, helping save space in control cabinets.

The power supply provides high efficiency up to 95.5% and very low no-load power consumption (<3 W). It also supports 200% peak power capability, making it suitable for loads with high startup current or short peak loads.

The unit includes comprehensive protection functions such as short circuit, overload, over-voltage and over-temperature protection. It also features a DC OK relay contact and Remote ON/OFF control for external power management. Fanless cooling by natural convection ensures reliable and silent operation. The operating temperature range is -40 to +85 °C.

With global safety certifications and high reliability, the XTR-480-12 is ideal for industrial control systems, semiconductor fabrication equipment, factory automation and electro-mechanical applications.

Key specifications:

• output voltage: 12 V DC

• rated current: 30 A

• rated power: 360 W

• peak power: up to 720 W (5 s)

• input: 3-phase 320–600 VAC

• efficiency: up to 95.5%

• mounting: DIN rail TS-35

• width: 63 mm

• operating temperature: -40…+85 °C

• warranty: 5 years
