XTR-960-48 is a 960 W ultra-slim three-phase DIN-rail power supply (48 V, 20 A) from Mean Well designed for industrial automation and control systems. The unit supports a wide three-phase input range of 320–600 VAC and features a compact 96 mm wide housing, allowing efficient installation in control cabinets.

The power supply provides high efficiency up to 96% with very low no-load power consumption (<3.1 W). It also supports 200% peak power capability, making it suitable for loads with high startup current or short peak loads.

The unit includes active current sharing, allowing up to 4 power supplies to operate in parallel for a total output power of up to 3840 W. Additional features include DC OK relay contact, Remote ON/OFF control, and ORing FET for redundant power systems. Fanless cooling by natural convection ensures reliable and silent operation. The operating temperature range is -40 to +85 °C.

With global safety certifications and high reliability, the XTR-960-48 is suitable for industrial control systems, semiconductor fabrication equipment, factory automation and electro-mechanical applications.

Key specifications:

• output voltage: 48 V DC

• rated current: 20 A

• rated power: 960 W

• peak power: up to 1920 W (5 s)

• input: 3-phase 320–600 VAC

• efficiency: up to 96%

• mounting: DIN rail TS-35

• width: 96 mm

• operating temperature: -40…+85 °C

• parallel operation: up to 4 units (3840 W)

• warranty: 5 years
